Артикул

9901002049

Семейство: LM7800 1.5-A, Wide VIN Fixed Voltage Regulators
Package Size:     mm2:W x L (PKG) : See datasheet (TO-220)
Iout(Max)(A):      1.5
Vout(Min)(V):      5
Vdo(Typ)(mV):      2000
Output Options:      Fixed Output
Vout(Max)(V):      15
Operating Temperature Range(C):      0 to 125,to
Regulated Outputs(#):      1
PSRR @ 100KHz(dB):      48
Output Capacitor Type:      Ceramic,Non-Ceramic
Fixed Output Options(V):      5,12,15
Thermal Resistance JA(°C/W):      24
Vin(Max)(V) :     30
Accuracy(%):      4
Vin(Min)(V):      7.5
Noise(uVrms):      40
Iq(Typ)(mA):      6
